Page 5 of 24
If necessary, the repeater relays must be inserted inside the box for
electrical locking commands and the signal light.
Figure 2: Position and dimensions of the non-removable cables
4,20 cm
2 meters
Shunt Box
Cable +12VDC
Cable LON
Cable IN 1
Cable IN 2
Cable OUT 1
Cable OUT 2
RTUL19
Figure 3: Shunt Box
15,60 cm
7,20 cm
6,10 cm
2 metri
8,00 cm
2-pole LON
cable
4 mm diamete
r
10 pole
cable
8.6mm
diamete
r
