Honeywell Thor VM3 Quick Start Guide

Connecting the Power Cable
The following power option is for 12-48VDC vehicles (10-60VDC
direct connection).
• Route the power cable away from the outside of the forklift.
• Choose a mounting location so that the power cable does not
extend outside the vehicle and that provides sufficient clearance
so that the power cable (especially the dock connector end) is not
pressed against part of the vehicle.
• Regularly inspect power cable for damage, especially in low
temperature environments.
CAUTION - For installation by trained service personnel only.
Fuse Requirements
WARNING - For proper and safe installation, the input power
cable must be connected to a fused circuit on the vehicle. If
the supply connection is made directly to the battery, the fuse
should be installed in the positive lead within 5 inches of the
battery’s positive (+) terminal. Use VM3055FUSE (or equiva-
lent) to install the fuse as shown below:
• F o r 12VDC input, use the 10A fuse from the kit or a slow
blow fuse that has a DC voltage rating greater than 12VDC.
• F o r 24VDC input, use the 6A fuse from the kit or a slow
blow fuse that has a DC voltage rating greater than 24VDC.
• F o r 36VDC input, use the 4A fuse from the kit or a slow
blow fuse that has a DC voltage rating greater than 36VDC.
• F o r 48VDC input, use the 3A fuse from the kit or a slow
blow fuse that has a DC voltage rating greater than 48VDC.
Note: For North America, a UL Listed fuse is to be used
!
!

Honeywell Thor VM3 Specifications

General

Stepping	D0
Tjunction	-40 °C
FSB Parity	No
Processor code	SR1X8
Processor cache	1 MB
Processor cores	2
Processor model	E3826
System bus rate	- GT/s
Processor family	Intel Atom®
Processor codename	Bay Trail
Processor frequency	1.46 GHz
Processor cache type	L2
Processor manufacturer	Intel
Processor package size	25 x 27 mm
Conflict-Free processor	Yes
Processor front side bus	- MHz
Processor operating modes	32-bit, 64-bit
Graphics & IMC lithography	22 nm
PCI Express configurations	1x1, 1x4, 2x1
Thermal Design Power (TDP)	7 W
Internal memory	4 GB
Internal memory type	DDR3-SDRAM
Storage media	Flash
Compatible memory cards	-
Internal storage capacity	64 GB
Display diagonal	12.1 \
Display brightness	900 cd/m²
Display resolution	1024 x 768 pixels
Graphics card	HD Graphics
Rear camera resolution (numeric)	- MP
Wi-Fi standards	802.11a, 802.11b, 802.11g
Bluetooth version	2.0+EDR
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
HDMI ports quantity	0
USB 2.0 ports quantity	1
I/O ports	1x CAN-bus, RF
Processor ARK ID	78477
Processor socket	BGA 1170
Operating temperature (T-T)	-30 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
Platform	Windows
Bundled software	Data Collection Engine, Microsoft Internet Explorer, Microsoft on-screen keyboard, Configuration Cloning Utility, Screen Blanking, Zoom Zone, Launcher
Operating system installed	Windows 7
AC adapter input voltage	90 - 240 V
Battery capacity	- mAh
Battery life (max)	0.5 h
Certification	EN 55024:2010, MIL-STD-810F, SAE-J1455, CCX
Device type	Tablet PC
Form factor	Slate
Product color	Grey, Silver
Protection features	Shock resistant, Vibration proof, Water resistant
International Protection (IP) code	IP66
Harmonized System (HS) code	84713000

Weight and Dimensions

Depth	62 mm
Width	318 mm
Height	260 mm
Weight	3000 g
