The following table provides reference based on furnace temperature, runtime, as well as whether the system fan is running
intermittently or continuous. These factors play a critical role in the GPD output of each humidifier style and model.
Furnace Run
time per day
Furnace
Temp
Additional Fan
Cirrculation (70°F)
HE225
Bypass
HE265
Bypass
HE365
Fan
HM506
TrueSTEAM
HM509
TrueSTEAM
HM512
TrueSTEAM
Evaporative
Pad
Steam-based
5 hrs (20%)
120°F
100%
6.7
9.5 10.1 6.5 9.0 12.0
110°F
100%
6.5
9.1 9.7 6.5 9.0 12.0
100°F
100%
6.2
8.8 9.3 6.5 9.0 12.0
90°F
100%
5.9
8.4 8.9 6.5 9.0 12.0
120°F
33%
3.8
5.4 5.7 6.5 9.0 12.0
110°F
33%
3.6
5.0 5.3 6.5 9.0 12.0
100°F
33%
3.3
4.7 4.9 6.5 9.0 12.0
90°F
33%
3.0
4.3 4.6 6.5 9.0 12.0
120°F
Intermittent
2.4
3.4 3.6 6.5 9.0 12.0
110°F
Intermittent
2.1
3.0 3.2 6.5 9.0 12.0
100°F
Intermittent
1.9
2.7 2.8 6.5 9.0 12.0
90°F
Intermittent
1.6
2.3 2.4 6.5 9.0 12.0
120°F
100%
7.6
10.8 11.4 6.5 9.0 12.0
110°F
100%
7.2
10.1 10.7 6.5 9.0 12.0
100°F
100%
6.7
9.5 10.1 6.5 9.0 12.0
90°F
100%
6.3
8.9 9.4 6.5 9.0 12.0
120°F
33%
5.2
7.3 7.8 6.5 9.0 12.0
110°F
33%
4.7
6.7 7.1 6.5 9.0 12.0
100°F
33%
4.3
6.1 6.5 6.5 9.0 12.0
90°F
33%
3.9
5.5 5.8 6.5 9.0 12.0
120°F
Intermittent
4.0
5.7 6.0 6.5 9.0 12.0
110°F
Intermittent
3.6
5.0 5.3 6.5 9.0 12.0
100°F
Intermittent
3.1
4.4 4.7 6.5 9.0 12.0
90°F
Intermittent
2.7
3.8 4.0 6.5 9.0 12.0
120°F
100%
8.7
12.3 13.1 6.5 9.0 12.0
110°F
100%
8.0
11.4 12.1 6.5 9.0 12.0
100°F
100%
7.4
10.5 11.1 6.5 9.0 12.0
90°F
100%
6.7
9.5 10.1 6.5 9.0 12.0
120°F
33%
6.9
9.8 10.3 6.5 9.0 12.0
110°F
33%
6.2
8.8 9.3 6.5 9.0 12.0
100°F
33%
5.6
7.9 8.4 6.5 9.0 12.0
90°F
33%
4.9
7.0 7.4 6.5 9.0 12.0
120°F
Intermittent
6.0
8.5 9.0 6.5 9.0 12.0
110°F
Intermittent
5.3
7.6 8.0 6.5 9.0 12.0
100°F
Intermittent
4.7
6.6 7.0 6.5 9.0 12.0
90°F
Intermittent
4.0
5.7 6.0 6.5 9.0 12.0
5 hrs (20%)
8 hrs (33%)
12 hrs (50%)

Honeywell TrueSTEAM Series Specifications

General

Installation Type	Duct-mounted
Type	Steam Humidifier
Installation	Professional installation recommended
Voltage	120V or 240V
Drain Required	Yes
Dimensions	Varies by model
Weight	Varies by model
Maintenance	Annual cleaning recommended
