UV100E ULTRAVIOLET SYSTEMS
13 68-0262—5
M20195A
CENTERS OF 2 IN. (51 MM)
HOLES FOR LAMP
3/32 IN. (3 MM) PILOT HOLES
FOR MOUNTING SCREWS
ALIGN EITHER OF THESE LINES AS CLOSE AS POSSIBLE TO DUCT CENTER LINE
INSTALLATION TEMPLATE
FOR AIR TREATMENT SYSTEM (DUAL-LAMP)
3/32 IN. (3 MM) PILOT HOLES
FOR MOUNTING SCREWS
CENTER OF AIRFLOW SENSOR HOLE
1-1/2 IN. (38) HOLE FOR AIRFLOW SENSOR
