UV100E ULTRAVIOLET SYSTEMS
68-0262—5 14
Fig. 20. Surface Treatment System template.
M20193A
CENTER OF 2 IN. (51 MM)
HOLE FOR LAMP
3/32 IN. (3 MM) PILOT HOLES
FOR MOUNTING SCREWS
ALIGN EITHER OF THESE LINES
AS CLOSE AS POSSIBLE TO
DUCT CENTER LINE
INSTALLATION TEMPLATE FOR SURFACE TREATMENT SYSTEM
