Table 89. NXVFD Application of Points.
Point Name Graphics Alarms Trends Commandable Internal Use Valid Values
Adjust Input / Actual Value 2 X X X X Units=%
Precision=1
Min.=-163.8
Max=163.8
Clear Counter X X X X Units=%
Precision=1
Min=0.0
Max=100.0
Drive Speed Setpoint X X X X Units=%
Precision=1
Min=0.0
Max=100.0
Free Analog / Input Actual Value 1 X X X X Units=%
Precision=1
Min.=-163.8
Max=163.8
Reset Fault X X X X Units=%
Precision=1
Min=0.0
Max=100.0
Torque Reference / Reference for PID X X X X Units=%
Precision=1
Min.=-163.8
Max=163.8
AC Fault Code X X X Units=%
Precision=1
Min.=-163.8
Max=163.8
Fault Active X X X True or False
DC Link Voltage X X X Units=%
Precision=1
Min=-163.8
Max=163.8
Drive Current X X X Units=A
Precision=1
Min=-3276.8
Max=3276.7
Drive Energy X X X Units=kW/hr
Precision=0
Min=0.0
Max=65535.0
Drive Power X X X Units=kW
Precision=1
Min=0.0
Max=6553.5
Ready X X X True or False
Running X X X True or False
Drive Speed X X X Units=%
Precision=1
Min=-163.8
Max=163.8
Active Fault Code X X X Units=null
Precision=0
Min=0.0
Max=65535.0
