Hooker ELECTRIC HBL328DCP - Page 4

Hooker Electric
Fishing Reel
Red Wire
Black Wire
Ground Not Used
Wiring
Conguration
12V DC System
24V DC System
Reference Chart for
Correct Gauge of Wire
Based Upon Length
Reference Chart for
Correct Gauge of Wire
Based Upon Length
12 VOLT BATTERY
12 VOLT BATTERY
12 VOLT BATTERY
Not Used
Not Used
Jumper
Wire
Not Used
Male Plug
Female Receptacle
Female Receptacle
To avoid depleting the
battery used to start
your boat, the reel
should be powered
from a separate deep
cycle battery.
4
Inline
Breaker
Inline
Breaker
