Please read the user manual entirely
before operating the reel. Important
notes and information are included
STOP
WIRING REQUIREMENTS
Please refer to the adjacent ABYC
certied E-11 chart for electrical
specications based on your
required wire length and ow of
amps used. Install a 40A breaker for
all reels except for the 130 Dual reel
which requires a 60A breaker. Install
the correct resettable breaker as
close as possible to the battery.
PLUG SUGGESTIONS
Male Plug
HBL328DCP
Female Plug
HBL328DCC
Receptacle
HBL328DCR
CRITICAL NOTE:
The red wire is positive, the
black wire is negative.
DO NOT wire backwards as this
will damage the reel and nullify
the warranty.
CIRCUIT LENGTH FLOW IN AMPS
Critical Voltage 40A 60A
0 to 6 ft. 0 to 1.8 M
10 feet 3.0 meters
15 feet 4.6 meters
20 feet 6.1 meters
25 feet 7.6 meters
30 feet 9.1 meters
40 feet 12.2 meters
50 feet 15.2 meters
60 feet 18.3 meters
70 feet 21.3 meters
80 feet 24.4 meters
90 feet 27.4 meters
100 feet 30.5 meters
110 feet 33.5 meters
120 feet 36.6 meters
130 feet 39.6 meters
8 AWG
6 AWG
4 AWG
2 AWG
1 AWG
1 AWG
0 AWG
0 AWG
3 0 AWG
4 0 AWG
3 0 AWG
2 0 AWG
2 0 AWG
6 AWG
4 AWG
2 AWG
Although this process uses information from ABYC E-11 to recommend wire size and
circuit protection, it may not cover all the unique characteristics that may exist on a
boat. Please call PENN Fishing Tackle with any questions.
