D
4-3
Clearing blockages
Disconnect cleaner from electrical
outlet.
Low suction or pick up may be due to
a blockage in the system. Refer to the
following steps to check for blockages
continuing with each step until the
blockage is found:
1. Check fullness of dirt cup; empty if
needed.
4-1
remove.
6. Remove agitator shield (see Fig. 3-18)
and remove any loose debris which may
have accumulated under it.
Checking airflow path
2. Plug cleaner in and turn ON. Check for
suction at end of hose (A).
If there is suction, continue with step 3.
If there is no suction, check for block-
age in hose and dirt tube as follows:
Look into opening (D) for blockages and
A
4-2
C
3. Turn cleaner OFF and unplug.
Check connection at hose tube (C);
remove any blockage.
Checking under bottom plate
4. Turn cleaner OFF and unplug.
5. Remove bottom plate, belt and agita-
tor (Figs. 3-15 and 3-16).
11
To Next Page
