Attach hose holder
Position hose holder (B) onto handle
by matching tabs on rack with
openings on back of handle. Make
sur
e bolts are through holes.
5
The assembled cleaner will look like
t
his drawing.
1-2
Attach upper handle
Remove clean solution tank (upper
tank) from carpet cleaner.
With cord hook (A) to back of carpet
cleaner, push upper handle down onto
lower handle. Push
bolts into holes on
front of handle. If bolts will not go
through hole easily handle is not
pushed completely down.
1-3
1-6
1-9
1-4
1-5
1-7
1-8
When handle sections are com-
pletely together
, squeeze trigger
(C) and depress Clean Surge™
button (D) on upper handle.
Y
ou will hear a “snap” when the
trigger rod is in place.
A
C
D
B
Replace clean solution tank (upper
tank) by positioning bottom first.
Press on tank handle to snap top of
tank into place.
Place nuts in recessed areas on
back of hose holder. Hold each
nut in place while tightening each
bolt secur
ely (from the front of the
handle) with a Phillips scr
ewdriver
.
Only two nuts are needed on this
model. The extra nut is not required
but has been provided for your con-
venience.
Attach tool holder
Remove tool and taped scr
ew fr
om
holder. Insert projections on holder
into slots on back of cleaner.
Slide holder down into place. Insert
screw at (D) and tighten with a
Phillips scr
ewdriver
.
D
Continued
➔
To Next Page
