PARTS DIAGRAM
1. Power On/Off
2. Power level adjust
3. Cord rewind
4. Dust cup handle
5. Handle
6. Angled pipe
7. Hose
8. Suction power control
9. Telescopic tube
10. Accessories storage
11. Multi floor tool
ASSEMBLING THE PRODUCT
Connecting the hose to the vacuum cleaner
Insert flexible hose into the air-intake:
Press the knob until it clicks into the position
Remove the flexible hose:
Unplug the appliance and press the knob at the end of the hose
Remove it from the air-intake opening.
Fitting the telescopic to the angled pipe
Fitting the multi floor tool to the telescopic tube
OPERATING INSTRUCTIONS
CAUTION: The air-intake nozzle and attachments must always be free of obstructions,
otherwise the motor will overheat and could be damaged.
