13
Maintenance
Cleaning & Maintaining the Brush Roll
Lower the handle to the reclined
position, and ip the unit over.
To access the brush roll, unscrew
the nozzle guard from the nozzle.
Remove the brush roll by
pulling it up and out from the
vacuum belt.
2
Remove any hair or
blockages.
3
Replace the brush roll and nozzle
guard. Secure with screws.
4
1
TIP: Rotate the brush roll manually to ensure the belt is properly installed.
LUBRICATION:
The motor and brush roll
are equipped with bearings which contain
sufcient lubrication for their lifetime.
The addition of lubrication could cause
damage. Do not add lubricant to motor or
brush roll.
CAUTION
To reduce the risk of injury from moving parts, unplug before servicing.
