Packing away and storage
Emptying and cleaning the dirt container
Cleaning the pre-motor filter
Cleaning the shroud
Post-motor filter is located in the
right side wheel. Hold the centre
of the wheel and twist wheel
cover anti-clockwise.
With the wheel cover off the
post-motor filter is
easily removed.
Tap all excess dirt off the filter.
Do not wash.
Cleaning the post-motor filter
NOTE: For convenience there is a parking slot located at the rear of the vacuum cleaner where the floor
head and tubes can be attached for storage and carrying.
NOTE: The shroud is accessed by removing the dirt container lid and is located underneath
the pre-motor filter.
Wash filters with warm water (40ºC MAX) at least every 3 months for best cleaning results. Do not use
the vacuum cleaner without all of the filters in place.
1
2
24 hr
24 hr
40˚ C max
40˚ C
max
MAINTENANCEMAINTENANCE
5
6
