15
3-24
B
A
When finished cleaning, follow “After
cleaning” instructions on page 11 and
“After using tool” instructions on page 13.
Continued
➜
10. For heavily soiled areas, it may be
necessary to repeat the cleaning
process. Make crisscrossing strokes to
the original pattern; overlap each pass.
Make no more than 2 passes with the
solution over any one area to prevent
over-wetting and damage to fabric.
If additional cleaning is necessary, wait
until the upholstery is completely dry
before using the tool again.
11. Empty recovery tank when the motor
sound becomes higher pitched and
there is a loss in suction (see “Automatic
shut-off”, page 8).
4. Maintenance
Removable
brushes
Your deep cleaner is equipped with
removable brushes for easy cleaning.
To remove brushes
Disconnect cleaner from electrical
outlet.
To prevent possible leaking, remove
clean solution tank and recovery tank.
Set tanks aside.
4-1
Press handle release pedal to lower han-
dle. Turn cleaner over so bottom is fac-
ing up.
4-2
B
B
B
A
Grasp inner portion of brush (A) and pull
brush assembly out slightly to reveal
latches (B).
4-3
B
B
B
B
Press all four latches (B) and pull brush
block out. The brushes can be cleaned
under running water.
4-4 4-5
C
C
D
D
E
F
To replace brushes
Align posts (C) on both ends of brush
assembly with slots (D) in cleaner hous-
ing.
Make sure that square post (E) also
aligns with square hole (F). Turn brushes
slightly until post fits easily into hole.
Press brush assembly firmly to snap into
place.
