Replacing the Dust Bag
If the Bag Check Indicator is red please check and if necessary, replace the dust
bag.
Lift the bag door release latch 1. [14] to open the bag door, close the bag to avoid dust
escaping by pulling the tongue and remove the bag. [15]. The full dust bag should be
disposed of correctly and carefully.
Fold a new bag as shown on the bag and fit by inserting the collar into the bag holder 2.
[16].
Close the bag door.3.
Remember: The bag check indicator may be red if an obstruction has occurred. In this
case, refer to ‘Removing a Blockage From the System’.
USING YOUR CLEANER
Cleaning the Filter
To maintain optimum performance of your cleaner, please wash the pre-motor filter and
exhaust filter after each 5 bag changes.
Cleaning the pre-motor filter:
Lift the Bag Door Release latch 1. [14] to open the bag door and remove the bag. [15]
To remove the pre-motor filter slide the pre-motor filter frame from the cleaner. 2. [17]
Remove the filter from the holder.3. [18]
Wash it in hand warm water, 4. [19] and allow it to dry thoroughly before replacing it in
the cleaner.
Cleaning the exhaust filter:
To remove the exhaust filter, unclip the exhaust filter cover 1. [20] and remove the exhaust
filter pack. [21]
Wash the filter in hand warm water 2. [19] and allow it to dry thoroughly before replacing
in the cleaner.
Remember: Do not use hot water or detergents. In the unlikely event of the filters
becoming damaged, fit a genuine Hoover replacement. Do not try and use the product
without a dust bag or filter fitted.
Cleaning the permanent cloth dust bag* :
To maintain optimum performance we recommend that you wash the permanent cloth
dust bag under hand warm water after every 5 full bags. Remove excess water and leave
to dry fully before replacing.
Removing a Blockage From The System
If the Bag Check Indicator is red:
1. Check if the bag is full. If so refer to ‘Replacing The Dust Bag’.
2. If is not full, then;
Do the filters need cleaning? If so refer to ‘Cleaning the Filter’.A.
Check if there is any other blockage in the system - Use a rod or a pole to remove B.
any blockage from Telescopic Tube or flexible hose.
Warning* : The bag check indicator will remain red if the cleaner is used when
the bag is full, if there is a blockage or if the filters are dirty. If used for a period over ten
minutes with the bag check indicator red, an electronic cut out will switch the
cleaner off to prevent any risk of overheating. If this should happen, switch the cleaner off,
unplug and correct the fault (see ‘Removing a blockage’). The cut out will automatically
reset upon switching the cleaner back on.
*Certain Models Only
**Nozzles may vary according to model
2
GB
Extract Power Cord and plug it into the power supply. Do not pull the cord beyond the 1.
red marker. [5]
Adjust the Telescopic Tube* to the desired height by moving the Telescopic Tube 2.
Adjusters* up and raise or lower the handle to the most comfortable cleaning position.
[6]
Carpet and Floor Nozzle**: Press the floor type selector pedal on the nozzle 3. [7] to select
the ideal cleaning mode for the floor type.
Hard Floor – Brushes are lowered to protect the floor.
Carpet – Brushes are raised for the deepest clean.
Switch the cleaner on by pressing the On/Off button on the cleaner main body. 4. [8]
Slide the Variable Power Control* to increase or decrease the suction. 5. [9]
Adjust the suction regulator* to the desired level. 6. [10]
Switch off at the end of use by pressing the On/Off button. Unplug and press the Cord 7.
Rewind Button to wind the power cord back into the cleaner. [11]
Parking and Storage - The tube can be parked for temporary storage 8. [12] while in use,
or in the storage position when not in use. [13]
TeliosPlusManual__1-3_union.indd 2 12/09/2011 19.37.28
