Hoover Telios Plus User Manual

GETTING TO KNOW YOUR CLEANER
ASSEMBLING YOUR CLEANER
Remove all components from the packaging.
1. Connect the hose to the cleaner main body, ensuring it clips and locks into position. To
release the hose: simply press the two latches on the hose end and pull. [2]
2. Connect the handle to the upper tube end. [3]
3. Connect the tube lower end to the carpet and oor nozzle**. [4]
A. Cleaner main body
B. On/Off Button
C. Cord Rewind Button
D. Variable Power Control*
E. Bag Check Indicator
F. Bag Door Release Latch
G. Bag Door
H. Pre-motor Filter
I. Exhaust Filter
J. Exhaust Filter Cover
K. Accessories door
L. Hose Handle
M. Suction Regulator*
N. Hose
O. Telescopic Tube*
P. Telescopic Tube Adjuster*
Q. Carpet and Floor nozzle(GP)**
R. Floor type selector
S. Crevice Tool
T. Furniture Nozzle
U. Dusting Brush
V. Pet Hair Remover Mini Turbo Nozzle*
W. Allergy Remover Mini Turbo Nozzle*
X. Grand Turbo Nozzle*
Y. Hard Floor Caresse Nozzle*
Z. Carpet & Rugs Nozzle*
CLEANER MAINTENANCE
Replacing the Dust Bag
If the Bag Check Indicator is illuminated please check and if necessary, replace the dust bag.
1. Lift the bag door release latch [14] to open the bag door, close the bag to avoid dust
escaping by pulling the tongue and remove the bag. [15]. The full dust bag should be
disposed of correctly and carefully.
2. Fold a new bag as shown on the bag and fit by inserting the collar into the bag holder [16].
3. Close the bag door.
Remember: The bag check indicator may be red if an obstruction has occurred. In this
case, refer to ‘Removing a Blockage From the System’.
Cleaning the Filter
To maintain optimum performance of your cleaner, please wash the pre-motor filter and
exhaust filter after each 5 bag changes.
Cleaning the pre-motor filter:
1. Lift the Bag Door Release latch [14] to open the bag door and remove the bag. [15]
2. To remove the pre-motor filter slide the pre-motor filter frame from the cleaner. [17]
3. Remove the filter from the holder. [18]
4. Wash it in hand warm water, [19] and allow it to dry thoroughly before replacing it in
the cleaner.
USING YOUR CLEANER
*Certain Models Only ** Certain models only, nozzles may vary according to model
Q1. Carpet Nozzle (CA)**
Q2. Hard Floor Nozzle (HF)**
2
GB
1. Extract Power Cord and plug it into the power supply. Do not pull the cord beyond the
red marker. [5]
2. Adjust the Telescopic Tube* to the desired height by moving the Telescopic Tube
Adjusters* up and raise or lower the handle to the most comfortable cleaning position. [6]
3. Carpet and Floor Nozzle**: Press the floor type selector pedal on the nozzle [7] to select
the ideal cleaning mode for the floor type.
Hard Floor – Brushes are lowered to protect the floor.
Carpet – Brushes are raised for the deepest clean.
4. Switch the cleaner on by pressing the On/Off button on the cleaner main body. [8]
5. Slide the Variable Power Control* to increase or decrease the suction. [9]
6. Adjust the suction regulator* to the desired level. [10]
7. Switch off at the end of use by pressing the On/Off button. Unplug and press the Cord
Rewind Button to wind the power cord back into the cleaner. [11]
8. Parking and Storage - The tube can be parked for temporary storage [12] while in use,
or in the storage position when not in use. [13]

Hoover Telios Plus Specifications

General

Power control	Electronic
Suction power	425 AW
Variable power	Yes
AC input voltage	220 - 240 V
Maximum input power	2400 W
Type	Cylinder vacuum
Cleaning type	Dry
Dust capacity	3.2 L
Product color	Red
Tube material	Metal
Housing material	Plastic
Dust container type	Dust bag
Cord length	6 m
Proper use	Home
Noise level	77 dB
Vacuum air filtering	HEPA
Dirt separating method	Filtering
Vacuum brushes included	Hard floor brush

Weight and Dimensions

Depth	443 mm
Width	303 mm
Height	242 mm
Weight	4900 g
Package weight	7600 g
