4
Push switch down to OFF position.
Slide handle section onto back of
handle.
Pull switch lock (C) above ON/ OFF
switch (D) straight out. Dispose of
switch lock.
If switch lock has come off during
assembly, make sure switch is in
OFF position (down) before plug-
ging into electrical outlet.
1-5
1-6
1-7 1-8
1-10
C
B
D
Remove cardboard (A) and four
screws from handle section. Discard
cardboard, but keep screws for
assembly (Figs. 1-7 and 1-8).
Cleaner Assembly
1-4
Snap tabs on hose holder (B) into
holes on handle section.
Place hose on holder.
Push screws into holes on back of
handle (Fig. 1-7) and hose holder
(Fig. 1-8).
Tighten screws securely with a
Phillips screwdriver.
REMOVE SCREWS AND CARDBOARD.
REMOVE SCREWS AND CARDBOARD.
