1. Introduction
Thank you for purchasing our mass flow controller SEC(SEF) -E400X series. Prior to using it,
please read this manual thoroughly to use it properly for a long period of time.
2. Specifications
2-1 Mass flow controller (SEC-E431X/SEC-E441X)
Type *1 SEC-E431X SEC-E441X
Standard flow rate range *2
(Full scale flow rate equivalent to N
2
)
50 / 100 SLM 200 SLM
Valve structure Closed when power is not supplied
Control range
5〜100% F.S.
Accuracy *3,*4
±1.0% F.S.
Operating temperature
5〜45℃
Responsibility (T98) *5 Within 1second (typical)
Linearity *3
Within ±0.5% of F.S.
Repeatability *3
Within ±0.5% of F.S.
Operating differential pressure *6,*7
100〜300 kPa (D) 200〜350 kPa (D)
Maximum operating pressure *6 350 kPa (G)
Pressure resistance *6 1000 kPa (G)
Leak integrity *8
1×10
-9
Pa･m
3
/sec (He) or less
Setting signal
0.25〜5V DC (Input impedance 1 MΩ or more)
Output signal
0〜5V DC (Minimum load resistance 2kΩ)
Power source
+15V DC±5% 50mA , –15V DC±5% 200mA
Wetted material
Stainless steel, Magnetic stainless steel,
Fluoro rubber, PTFE
Standard fittings 3/8inch Swagelok or equivalent
*1:This product is in conformity with RoHS directives.
*2:SLM denotes gas flow rate in l/min.
*3:Accuracy, linearity and repeatability are guaranteed for the calibration gas.
*4:Temperature for accuracy guarantee is in accordance with SEMI standard E56−1296.
*5:A time required to stay within the full scale ±2% from the minimum controllable flow rate.
*6:(D) indicates differential pressure. (G) indicates gauge pressure.
*7:The operation differential pressure may differ depending on the specifications.
*8:
Mechanical leak rate (SEMI standard E16−90).
