Horstmann ChannelPlus H17XL Series 2 User Manual

9
Adjusting Time and Date
The ChannelPlus H17XL Series 2 timeswitch has been set with the current time and date
during manufacture. No alteration should be required to the time and date, however if any
modication is required please refer to the owchart below.
PLEASE NOTE: Any alteration to the current time or date
will cancel any Holiday programme set. It will also
cause any Boost or Advance operations to be cancelled.
Press the green
‘SET’ button
Use the ‘+’ and ‘-’
buttons to adjust
‘TIME AND DATE’
Use the ‘+’ and ‘-’
buttons to adjust
THE MONTH
Use the ‘+’ and ‘-’
buttons to adjust
THE YEAR
Use the ‘+’ and ‘-’
buttons to adjust
THE CURRENT TIME
Use the ‘+’ and ‘-’
buttons to select
‘SET DEFAULTS’
Open cover
Press ‘ENTER’
Press ‘ENTER’
Press ‘ENTER’
Press ‘ENTER’
Press ‘ENTER’
Press ‘ENTER’
Press the green
‘SET’ button
Press the green
‘SET’ button
Close cover

 








 


Use the ‘+’ and ‘-’
buttons to adjust
THE DAY
SET ON/OFF TIMES
SET HOLIDAY MODE
SET DEFAULTS
SET DEFAULTS
TIME AND DATE
CLOCK OPTIONS
HEADINGS
TIME AND DATE
23.00
30 SEP 2009
SAMPLE DISPLAYS
SET DEFAULTS
TIME AND DATE
23.00
30 SEP 2009
