"SX" PANEL
"O" PANEL
See page 4 for
Autolock setup
•Install a new continuous belt
•Make splice connection at the drive assembly
•Tension the new belt
"O" PANEL
4th Step
2.206d
Mount the autolock and relocate the
closed monitor switch
(see steps 7,8 & 9 page 1)
"SX" PANEL
5th Step
Put the door at full open and mark this position.
The belt idler will have to be moved beyond this point.
Autolock Installation for 2001 & 2003 O-SX units
BELT DRIVE SUPPLEMENTAL INSTRUCTIONS
"SX" PANEL
Move the idler to the end of the header.
(allow space for tightening)
2nd Step
1-800-531-3111
1st Step
•Dismount the wheel carriages and move the
drive assembly to the back and the idler to the
front.
•Mount the keeper to the drive assembly.
(see steps 3 thru 6 page 1)
3rd Step
CAUTION:
Disconnect power before
starting this procedure.
S200.1
10/99
To Next Page
