15. Reverse Display
Press and hold the reverse button, the vehicle enters reverse mode. Th
en turn the throttle, the vehicle goes backward.
16. Sliding Screen
When the distance between the electronic key and the vehicle is less
than 1.2 meters, swipe the screen to the right, start the motorcycle,
swipe the screen to the left and stop the motorcycle.
Schematic Diagram of Combination Switch
Left hand combination
switch
①
High/low beam
Turn the switch upward, the light
is high beam; Turn the switch
downward, the light is low beam
Right hand combination
switch
⑤
Motorcycle lamp switch
Turn the button to the lower side,
all the lamps are turned off
Turn the button to the upper side,
the headlamp is turned on.
