I. Construction and Water/Refrigeration Circuit Diagram
A. Construction
1. Icemaker
Rear
Front
Top Panel
C-80BAJ-AD Shown
C-80BAJ-AD Shown
Inlet Water Valve
Water Reservoir
Float Switch
Compressor
Evaporator
Assembly
Gear Motor
Drier
Drip
Tray
Gear Motor
Drain Pan
Evaporator Condensate
Drain Pan
Lower Rear Panel
Power Cord
Drain Valve
Upper Rear Panel
Top Panel
Ice Discharge
Opening
Scoop Holder
Front Panel
Control Switch
Louver
Bin Control
Thermostat
Bulb
Slope
Magnet Catch
Door
Power Cord
Bin Control
