37
E. Optional Drain Pump HS-5061
If the optional drain pump (HS-5061) is installed, test its operation at least twice a year
as outlined below. Note that the pump has power even when the control switch is in the
"OFF" position.
NOTICE
If the optional drain pump is not operating properly, it will adversely affect
performance, component life, and warranty coverage and may result in costly water
damage.
1) Move the control switch to the "OFF" position, then unplug the appliance from the
electrical outlet. WARNING! To reduce the risk of electric shock, do not touch the
control switch or plug with damp hands.
2) Remove all ice from the storage bin.
3) Plug the appliance back in.
4) Slowly pour 24 to 30 oz. (710 to 890 ml) of water over the storage bin drain hole in the
storage bin.
5) If water pumps out properly and the drain pump then de-energizes, proceed to step 6.
If water does not pump out properly and/or the drain pump does not de-energize, the
appliance must be serviced by a qualied service technician before proceeding.
6) Move the control switch to the "ICE" position.
7) Pour another 24 to 30 oz. (710 to 890 ml) of water into the appliance's ice storage bin,
then completely restrict the discharge hose while the drain pump is operating.
See Fig.34. Pour more water into the appliance's ice storage bin until the appliance
turns off. The drain pump will continue to operate. Check for leaks.
8) Remove the discharge hose restriction and allow the water to be pumped out normally.
Power to the appliance will be restored when the water in the drain pump returns to a
normal level.
9) If the appliance fails to turn off with the discharge hose restricted or the pump fails to
pump out the water, the appliance must be serviced by a qualied service technician.
Fig. 34
Discharge Hose
