20
g. Remove the 2 screws from the lower part of the thermostat bracket (plastic) and use
them to attach the thermostat extension bracket (stainless) to the thermostat bracket
(plastic). See Fig. 5.
2) Replace the panels and baffle in their correct positions unless you are installing
anupper unit. If you are installing an upper unit, see "II.D.3. Installation of Upper Unit."
Fig. 5
Thermostat Extension
Bracket (stainless)
Thermostat Bracket
(plastic)
Thermostat Bulb
Attachment (plastic)
