HOTATA 3106 - Latch and Strike Plate Installation

Install the latch and strike
up
up
up
up
up
Installation Guide
No adjustment is required.
Proceed to next step.
Twist the latch and adjust
the bolt length.
(As shown below)
Make sure the hole in the door frame is
drilled a minimum of 1"(25mm) deep.
1.Insert the latch bolt into the door.
Actural Size
3/4"(19mm)Screws-2 ea.
Make sure the +-shaped hole is
in the bottom position
YES NO
2-3/4"70mm
YES NO NO
2.Install strike on the door frame.
Actural Size
3/4"(19mm)Screws-2 ea.
