Indesit Company
Service Manual UK English
6. Open the evaporator area.
7. Disconnect the fan/heating element connector.
NOTE: - All components will now be accessible.
B) Disassembly of Ozone Generator
1. Remove the 2 screws securing the ozone generator.
2. Unplug the ozone generator from its power supply.
IMPORTANT NOTE: - Don’t forget that the ozone generator is a single unit and must be replaced
as a whole.
7
1 2
