EN
16
Overall view
Description of the
appliance
1. Upper rack
2. Upper sprayer arm
3. Tip-up compartments
4. Rack height adjuster
5. Lower rack
6. Lower sprayer arm
7. Cutlery basket
8. Washing filter
9. Salt dispenser
10. Detergent and rinse aid dispensers
11. Data plate
12. Control Panel
***
***Only in completely built-in models.
* Only available in selected models.
Control panel
The number and type of wash cycles and options may vary depending on the dishwasher model.
ON/OFF/RESET
button
ON/OFF
indicator light*
Select wash
cycle knob
Washing
indicator light
Drying
indicator light
End indicator
light
Start/Pause button
and indicator light
Low Salt
indicator light*
Low Rinse aid
indicator light*
