THANK YOU FOR BUYING A HOTPOINT PRODUCT.
In order to receive a more complete assistance, please
register your product on www.hotpoint.eu/register
Policies, standard documentation, ordering of spare parts and additional product information can be
found by:
• Visiting our website docs.hotpoint.eu and parts-selfservice.whirlpool.com
• Using QR Code
• Alternatively, contact our After-sales Service (See phone number in the warranty booklet). When
contacting our After-sales Service, please state the codes provided on your product’s identifi cation plate.
THANK YOU FOR BUYING A WHIRLPOOL PRODUCT.
In order to receive a more complete assistance, please register
your product on www.whirlpool.com.hk
You can download the user manual by:
• Visiting our website
www.whirlpool.com.hk
• Alternatively, contact our After-sales Service (See phone number in the warranty booklet). When
contacting our After-sales Service, please state the codes provided on your product’s identifi cation plate.
EN
Quick guide
Before using the appliance carefully read the Safety
Instructions.
xxxxxxxxxxxx
xxxx
Power consumption
off-mode (Po) - Watts 0.42
left-on mode (Pl) - Watts 2.00
Programs kg kWh Minutes
Eco*
9 1.69 215
Eco
4.5 0.81 110
Synthetics 4 0.94 113
*This is the reference programme for the energy label and suitable to
dry normal wet cotton laundry. This is the most efficient programme
in terms of energy consumption for drying wet cotton laundry.
(Standard/Default starting configuration)
Cleaning the tumble dryer
• The external metal, plastic and rubber parts can be cleaned
with a damp cloth.
• Clean the front air intake grille regularly (every 6 months)
with a vacuum cleaner to remove any lint, fluff or dust
deposits. Furthermore, remove any lint deposits from the
filters area, using a vacuum cleaner every so often.
• Do not use solvents or abrasives.
AB
1
4
2
3
C
CARE AND MAINTENANCE
WARNING: unplug the dryer during the cleaning and
maintenance procedures.
Emptying the water tank after each cycle (see Fig. A).
Pull the container out of the dryer and empty it into a sink or
other suitable drain, then place it back properly. Do not use the
dryer without having inserted the container back in place.
Cleaning the door lter after each cycle (see Fig. B).
Pull the filter out and clean it by removing the lint from the filter
surface under running water or using a vacuum cleaner. For optimal
performance, dry up the filter before inserting it back in place.
Do not use the dryer without having reinserted the lter in place.
Remove the door filter as described below:
1. Open the door and pull the filter upwards.
2. Open the filter and remove the lint from all its parts. Replace the
filter correctly making sure it is fully seated.
Cleaning the bottom lter when the relevant indicator
turns on (see Fig. C).
Pull the filter out and remove the lint from its surface by washing
it under runing water or by using a vacuum cleaner.
However, it is advisable to clean this filter after each cycle to
optimise drying performance.
Do not use the dryer without having reinserted the lter in place.
Remove the bottom filter as described below:
1. Open the bottom cover;
2. Take the handle and pull the filter out.
3. Open the rear side of the filter and remove the lint from the
inner surface of the mesh.
4. Clean the filter chamber avoiding the direct contact with the fins.
5. Close the rear side of the filter and place it back by checking it
is perfectly integrated into its seat.
6. Lower the filter handle and close the bottom cover.
7. Make sure the air intake is free.
The lters are essential parts for drying. They are intended
to collect the lint formed during the drying process. In case
of clogged lters, the air ow inside the dryer would be
seriously aected: the drying times would be longer, the
energy consumption would increase and the dryer could be
damaged. If these procedures are not carried out properly,
the dryer may not start.
TRANSPORT AND HANDLING
Never lift the dryer by holding it at the worktop.
1. Unplug the dryer.
2. Remove the water from the water tank completely.
3. Make sure that door and water tank are properly closed.
4. If the drain hose is connected to your drainage system,
re-connect it to the back of the dryer (see "Installation" section
in the Safety Instruction guide).
Heat Pump System
The heat pump contains fluorinated greenhouse gases,
contained in a hermetically sealed unit. This sealed unit contains
0.43 kg of the R134a gas. GWP = 1430 (1 t CO).
PRODUCT DESCRIPTION
1. Water Tank
2. Air Intake
3. Bottom filter
4. Door filter
