1700 SERIES PRESSURE WASHER OPERATOR’S MANUAL
17
Hotsy 1700 • 97-6419 • Rev. 7/06
ITEM PART NO. DESCRIPTION QTY
37 799004 Nozzle, SAQCMEG 0006 Red
(1720, 1722, 1723, 1724, 1725) 1
38 799003 Nozzle, SAQCMEG 00055 Red
(1710, 1740, 1742, 1743, 1744,
1745) 1
799006 Nozzle, SAQCMEG 0007 Red
(1750, 1752, 1753, 1754, 1755) 1
39 799012 Nozzle, SAQCMEG 1504 Yellow
(1730, 1732, 1733, 1734, 1735) 1
799016 Nozzle, SAQCMEG 1506 Yellow
(1720, 1722, 1723, 1724, 1725) 1
799015 Nozzle, SAQCMEG 15055 Yellow
(1710, 1740, 1742, 1743, 1744,
1745) 1
799018 Nozzle, SAQCMEG 1507 Yellow
(1750, 1752, 1753, 1754, 1755) 1
40 799144 Nozzle, SAQCMEG 2504 Green
(1730, 1732, 1733, 1734, 1735) 1
799392 Nozzle, SAQCMEG 2506 Green
1720, 1722, 1723, 1724, 1725) 1
190004 Nozzle, SAQCMEG 25055 Green
(1710, 1740, 1742, 1743, 1744,
1745) 1
799198 Nozzle, SAQCMEG 2507 Green
(1750, 1752, 1753, 1754, 1755) 1
41 799024 Nozzle, SAQCMEG 4004, White
(1730, 1732, 1733, 1734, 1735) 1
799028 Nozzle, SAQCMEG 4006, White
(1720, 1722, 1723, 1724, 1725) 1
799027 Nozzle, SAQCMEG 40055 White
(1710, 1740, 1742, 1743, 1744,
1745) 1
799030 Nozzle, SAQCMEG 4007 White
(1750, 1752, 1753, 1754, 1755) 1
42 630013 Label, Hotsy, 1700 Series 1
43 834086 Label, Hotsy Logo Stripe 2
44 Bushing, See Specifications Pages 20-21
45 Bushing, See Specifications Pages 20-21
46 Pulley, See Specifications Pages 20-21
47 Pulley, See Specifications Pages 20-21
48 Belt, See Specifications Pages 20-21
49 661426 Swivel, 1/2" JIC Fem, 3/8" Male 1
50 630009 Screw, 1/4"x1/2" BH SOC ES 14
51 936438 Washer, 3/8" x 1" Steel 4
52 886541 Hour Meter, Hobbs, 115 VAC 1
53 612984 Bolt, 3/8" x 1", NC HH (All Models
Except 1710) 4
1700 SERIES -EXPLODED VIEW PARTS LIST (CON'T)
ITEM PART NO. DESCRIPTION QTY
53 612950 Bolt, 5/16" x 1" NC HH (1710) 4
54 646663 Label, Warning, Exposed
Pulley 1
55 646665 Label, Cold Water Outlet 1
56 630814 Cord, GFCI, 230V, 40A, 8-3 Cord
w/Plug (1730,1732) 1
825985 Service Cord 12/4 (1723, 1724,
1725, 1734, 1735,1745,
1755) 10 ft.
630936 Service Cord 10/4 (1733) 10 ft.
645893 Service Cord 8/4 (1743, 1744
1753,1754) 10 ft.
631004 GFCI Cord 230V/30 Amp, 10-3
Cord (1720, 1722) 1
981000 GFCI Cord 120V/20 Amp w/36',
12-3 Cord (1710) 36 ft.
630815 Cord, GFCI, 230V, 50A, 37' Cord
w/Plug (1740,1742,1750,1752) 1
57 646359 Label, GFCI 1
58 826029 Strain Relief 1" 1
6-051930 Connector, 1" (1740, 1742, 1750,
1752) 1
59 825989 Service Cord 12/3 (1710) 4.25 ft.
825985 Service Cord 12/4 (1723,1724,
1735, 1725, 1734, 1745,
1755) 3.33 ft.
826010 Service Cord 10/3
(1722,1720) 3.33 ft.
826020 Service Cord 8/3
(1730,1732) 3.33 ft.
630936 Service Cord 10/4 (1733) 3.33 ft.
645891 Service Cord 6/3
(1740,1742,1750,1752) 3.33 ft.
645893 Service Cord 8/4 (1743, 1744,
(1753,1754) 3.33 ft.
60 875473 Strain Relief, Strt, LQ Tite 3234
Large (1720, 1722, 1723, 1724,
1725, 1730, 1732, 1733, 1734,
1735, 1745, 1755) 1
903087  Locknut, 3/4" Conduit (1720,
1722, 1723, 1724, 1725, 1730,
1732, 1733, 1734, 1735, 1745,
1755) 1
876029 Strain Relief LQ Tite (1710) 1
903086  Locknut, 1/2" Conduit (1710) 1
6-05170 Strain Relief, 3/4" (1740, 1742,
1743, 1744, 1750, 1752, 1753,
1754) 1
