Hoval CombiVal - Mount Accessories and Finalize

Montageanleitung Isolationspakete CV-MV (GB) Rev.03
Stand: 14.11.2007
Mount thermometer with enclosed L-shaped metal bracket (Figure 4-5).
Figure 4 Figure 5
Mount sensor with enclosed omega-shaped clips (Figure 6-7).
Figure 6 Figure 7
Place rosettes at the connections. Plug on missing cover caps (incl. insulation).
Fix Hoval nameplate and installation instruction at calorifier insulation.
