Howard Wright M9 TRANSFER - AUXILIARY AND STORAGE ACCESSORIES

24 M9 Transfer Instructions For Use (M999-19, Version 10, 2021-12)
7.7 URINE BOTTLE CARRIER
WARNING: The safe working load of the urine bottle carrier is 2kg.
To fit:
• Place the hook over the top rail of the siderail.
NOTE: Please see Urine Bottle Carrier Instructions for use (M799-61)
for further information.
7.8 MONITOR TRAY
WARNING: The safe working load of the monitor tray is 25kg.
WARNING: Ensure all equipment is secured in place using the included
straps before manoeuvring the stretcher.
WARNING: Keep hands and fingers clear of the table top pivots when
folding the monitor tray.
WARNING: Do not use the monitor tray together with the orthopaedic
frame (M748-01).
CAUTION: Ensure patients feet are clear of the monitor tray.
The monitor tray is for supporting monitors or instruments at the foot end of
the stretcher only.
Fold up:
• Stand at the foot end facing the stretcher.
• Lift the monitor tray up and fold over towards the head end.
Fold down:
• Stand at the foot end facing the stretcher.
• Using both hands, lift the tray up and fold backwards towards the foot
end.
NOTE: Please see Monitor Tray Instructions for use (M799-57) for
further information.
7. ACCESSORIES
Figure 34. Monitor tray folded up
Figure 35. Monitor tray folded down
Figure 33. Urine bottle carrier
