Howdens LAM2202 - General Information & Operation; E T X; Control Panel Layout

www.howdens.com
Page _ 6
1.
2.
3.
5.
6.
1.
2.
3.
4.
5. 7.
6.
4.
1. Exhaust / Recirculation Vent
2. Cabinet Door / Facia
3. Air Intake
4. Wall Cabinets
5. Light
6. Control Panel
General Information & Operation
tuoyaL rotcartxE
Control Panel Layout
1. Light Off
2. Light On
3. Motor Neon Indicator
4. Extraction Off
5. Extraction Level Low
6. Extraction Level Medium
7. Extraction Level High
