Item Component Spare part
number
(1) Display assembly (touch or non-touch)
NOTE: For display assembly spare part information, see Display assembly subcomponents
on page 21.
not spared
(2) Top cover/keyboard
NOTE: For a detailed list of keyboard country codes, see Top cover/keyboard on page 82.
Models in the following color: jet black 925008-xxx
Models in the following color: snow white 925009-xxx
Models without a backlight in the following colors: pike silver, silk gold, empress red, smoke gray,
marine blue, amethyst purple, pale mint, sparkling black
925010-xxx
Models with a backlight in the following colors: pike silver, silk gold, empress red, smoke gray, marine
blue, amethyst purple, pale mint, sparkling black
NOTE: Available only for the following countries and regions: the United States (-001), India (-002),
English/French Canada (-DB1).
925011-xxx
Models without a backlight for use in the United States in the following color: rose gold 925564-001
Models with a backlight for use in the United States in the following color: rose gold 925565-001
(3) RTC battery 922847-001
(4) Touchpad button board 924993-001
(5) Power button board 924994-001
(6) Solid-state drive, M.2
512 GB 763008-017
256 GB 865902-017
128 GB 827560-048
(7) Power connector cable 931613-001
(8) USB board 924991-001
Heat sink assembly (includes replacement thermal materials)
(9) For use in models with UMA graphics and AMD dual core, 6 W processors 925019-001
(9) For use in models with UMA graphics and AMD dual core, 15 W processors 925020-001
(10) For use in models with UMA graphics memory and AMD quad core processors 925017-001
(11) For use in models with discrete graphics memory and AMD dual core processors 925021-001
(11) For use in models with discrete graphics memory and AMD quad core processors 925018-001
(12) Fan 925012-001
(13) Memory module, DDR4-2400
8-GB 862398-855
4 GB 862397-855
2 GB 864271-855
(14) WLAN module
18 Chapter 3 Illustrated parts catalog
