System board
NOTE: The system board spare part kit includes replacement thermal materials.
Description Spare part number
System board (includes replacement thermal materials):
All system boards use the following part numbers:
xxxxxx-001: Non-Windows operating systems
xxxxxx-601: Windows 10 operating system
For use in models with discrete graphics memory
AMD A12-9720P processor and 4 GB of discrete graphics memory 924722-xx1
AMD A12-9720P processor and 2 GB of discrete graphics memory 924726-xx1
AMD A10-9620P processor and 2 GB of discrete graphics memory 924723-xx1
AMD A9-9420P processor and 2 GB of discrete graphics memory 924724-xx1
AMD A9-9420P processor and 2 GB of discrete graphics memory (models with both hard drive and solid-
state drive)
929587-xx1
AMD A6-9220P processor and 2 GB of discrete graphics memory 924725-xx1
For use in models with UMA graphics memory:
AMD A12-9720P processor 924717-xx1
AMD A10-9620P processor 924718-xx1
AMD A9-9420P processor 924719-xx1
AMD A6-9220P processor 924720-xx1
AMD E2-9000e processor 924721-xx1
Before removing the system board, follow these steps:
1. Shut down the computer. If you are unsure whether the computer is o or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by rst unplugging the power cord from the AC outlet and then
unplugging the AC adapter from the computer.
4. Remove the battery (see Battery on page 32).
5. Remove the optical drive (see Optical drive on page 33), if installed.
6. Remove the bottom cover (see Bottom cover on page 43).
7. Remove the WLAN module (see WLAN module on page 46).
8. Remove the memory module (see Memory module on page 48).
9. Remove the solid-state drive (see Solid-state drive (SSD) on page 55).
To remove the system board:
66 Chapter 6 Removal and replacement procedures for Authorized Service Provider parts
