Optical drive
Description Spare part number
DVD+/-RW Double-Layer SuperMulti Drive 920417-008
Optical drive bracket 924979-001
Optical drive bezel
Pike silver 924917-001
Silk gold 924918-001
Smoke gray 924919-001
Marine blue 924920-001
Amethyst purple 924921-001
Pale mint 924922-001
Jet black 924923-001
Snow white 924924-001
Empress red 924296-001
Rose gold 924297-001
Before removing the optical drive, follow these steps:
1. Shut down the computer. If you are unsure whether the computer is o or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by rst unplugging the power cord from the AC outlet and then
unplugging the AC adapter from the computer.
4. Remove the battery (see Battery on page 32).
To remove the optical drive:
1. Remove the Phillips PM2.5×11.0 screw (1) that secures the optical drive to the computer.
Component replacement procedures 33
