Bottom cover
Description Spare part number
Bottom cover for use in black and green models 926864-001
Bottom cover for use in black and white models 926863-001
Before removing the bottom cover, follow these steps:
1. Shut down the computer. If you are unsure whether the computer is o or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by rst unplugging the power cord from the AC outlet and then
unplugging the AC adapter from the computer.
4. Remove the battery (see Battery on page 37).
To remove the bottom cover:
1. Position the computer upside down with the front toward you.
2. Remove the two upper rubber feet (1).
3. Remove the two Phillips PM2.5×6.0 screws (2) under the two upper rubber feet that secure the bottom
cover to the computer.
4. Remove the ve Phillips PM2.0×6.0 screws (3) that secure the bottom cover to the computer.
Component replacement procedures 35
