Item Icon Component Description
(7) AC adapter and battery light (continued)
●
O: The battery is not charging.
(8) Power connector Connects an AC adapter.
Bottom
Component Description
Vent Enables airow to cool internal components.
NOTE: The computer fan starts up automatically to cool internal
components and prevent overheating. It is normal for the internal
fan to cycle on and o during routine operation.
Bottom 13
