Item Component Spare part number
(9) For use only on computer models equipped with a graphics subsystem with UMA memory 926846-001
(10) Solid-state drive (2280 M.2, SATA-3):
512-GB with TLC 763008-019
256-GB with TLC 760615-038
128-GB with TLC 759848-018
256-GB 865902-019
128-GB 827560-050
(11) Memory modules (2, DDR4-2400, 1.2-V):
8-MB 862398-855
4-MB 862397-855
2-MB 864271-855
(12) USB port board (includes power light actuator, hard drive light actuator, card reader slot,
and USB port; does not include USB port board cable)
926854-001
USB port board cable (not illustrated, includes double-sided adhesive): 926842-001
(13) WLAN module:
Intel Dual Band Wireless-AC 7265 802.11 AC 2×2 WiFi + Bluetooth 4.2 Combo Adapter (non-
vPro)
901229-855
Intel Dual Band Wireless-AC 3168 802.11AC 1×1 WiFi + Bluetooth 4.2 Combo Adapter (non-
vPro)
863934-855
Realtek RTL8723BE-VB 802.11 bgn 1×1 WiFi + Bluetooth 4.0 Combo Adapter 855106855
Realtek RTL8723DE 802.11 bgn 1×1 WiFi + Bluetooth 4.2 Combo Adapter 927230-855
(14) Power connector cable 810327-006
(15) Battery (3-cell, 41-WHr, 3.6-AHr, Li-ion) 920070-855
(16) Hard drive (does not include hard drive bracket or hard drive cable):
2-TB, 5400-rpm, SATA, 7.0-mm hard drive 912487-855
1-TB, 5400-rpm, SATA, 7.0-mm, Hybrid 8.0-GB hard drive 731999-005
1-TB, 5400-rpm, SATA, 7.0-mm hard drive 778192-005
500-GB, 5400-rpm, SATA, 7.0-mm hard drive 778186-005
NOTE: The hard drive spare part kit does not include the hard drive bracket or the hard drive cable. The hard drive
bracket is available using spare part number 926848-001. The hard drive cable is available using spare part number
926844-001
(17) DVD±RW DL SuperMulti Drive (does not include optical drive bezel or optical drive bracket) 920417-003
NOTE: The optical drive spare part kit does not include the optical drive bezel or the optical drive bracket. The optical
drive bezel is available using spare part number 926835-001. The optical drive bracket is available using spare part
number 926850-001
(18) Bottom cover 926832-001
Rubber Foot Kit (not illustrated, includes Mylar screw cover) 926855-001
26 Chapter 3 Illustrated parts catalog
