HP 16700A - Page 50

49
16533p03
Single-Card Module
HP 16533/34A CalibrationHP 16533/34A Calibration
HP 16533/34A CalibrationHP 16533/34A Calibration
Connect the BNC Tee and the
(equal length) BNC cables to the
module.
7
For more accurate calibration, allow the system
30 minutes to warm up.
6
15
15
30
0
for HP 16600A Series/ HP 16700A/ HP 16702A
