HP 16700A - HP 16600 A Series, HP 16700 A, HP 16702 A; Mouse and Keyboard

Keyboard
Mouse
Keyboard Mouse
RS 232 Monitor Parallel Printer
LAN
10Base-T
SCSI-2 Single Ended
LAN
10Base2
Target
Control
Out - Port - In
To 16701 Expansion FrameTo 16701 Expansion Frame
Target
Control
Target
Control
Keyboard Mouse
6
HP 16700A
or
HP 16702A
HP 16600A Series Frame
16allp06
The system mouse and
keyboard must be installed
for the system to boot up
properly.
Once enabled on the LAN,
the system can be operated
remotely without a keyboard
or mouse.
HP 16600A Series/ HP 16700A/ HP 16702A
Mouse and KeyboardMouse and Keyboard
Mouse and KeyboardMouse and Keyboard
