HP 16700A - Page 55

54
16533p08
for HP 16700A and HP 16702A
Multi-Card Module
HP 16533/34A CalibrationHP 16533/34A Calibration
HP 16533/34A CalibrationHP 16533/34A Calibration
Each of the individual boards of a multi-card module must first be calibrated as a
single. (See previous pages: .)
The following example is of a two-card module arrangement. Up to four cards may be
configured as a module in an HP 16700A or an HP 16702A mainframe.
HP 16533/34A Single-Card Module
Connect the module cables.
1
Exit the current session and restart.
2
Master
1
2
3
