HP 16700A - Page 61

80 Pin
Cable
100 Pin
Cable
Other modules
or filler panels.
J5J7
J6J7
60
16550p06
HP 16550AHP 16550A
HP 16550AHP 16550A
2-Card Module
Gently slide the module into the frame and
hand tighten the thumb screws.
If you are inserting more than one module,
the tightening order is bottom module to top
module.
for HP 16700A and HP 16702A
