for HP 16700A and HP 16702A
HP 16715/16/17AHP 16715/16/17A
HP 16715/16/17AHP 16715/16/17A
Single-Card Module
If ordered by themselves, all HP 16715, 16, and 17A's are cabled at the factory as a single-
card module. Be sure the is connected as shown below.2x10 cable
2x10 Cable
Master
J3
J6J8 J5J7 J4
The require software Rev. A.01.40.00 or higherHP 16715, 16, and 17A's . See the
Software Installation chapter in this book. Select HP 1660x-70x.
