QuickSpecs
hp Modular Power Distribution Units
(Zero-U/1U Modular PDUs)
DA-11041 World Wide — Version 3 — December 11, 2002 5
ADDITIONAL SPECIFICATIONS
Low Voltage 24A
(NA/JPN/LA)
High Voltage 16A
(WW)
High Voltage 24A
(NA/JPN/LA)
High Voltage 32A
(INTL)
High Voltage 40A
(WW)
Part Number 252663-D71 252663-B24 252663-D72 252663-B31 252663-B21
Current (max) 24A 16A 24A 32A 40A
AC Voltage Range 100-127V 200-240V 200-240V 200-240V 200-240V
Frequency (Hertz) 50/60Hz 50/60Hz 50/60Hz 50/60Hz 50/60Hz
Load Capacity (VA) 2880 (@120V) 3680 (@230V) 4992 (@208V) 7360 (@230V 9200 (@230V)
Output Circuit
Breakers
4x15A 2X10A 4x15A 4x15A 4x15A
Overload Protection YesYesYesYesYes
Indicator Lights Indicator light on each of the Extension Bars; and a main AC pilot light on the Control Unit
Plugs and Cables
Control Unit (x1)
Input: 3.6m attached
cable with L5-30P
Output: Four IEC320-
C19 (12A ea)
Input: Detachable
input power cord
(country specific) with
a IEC 320-C20 inlet
Output: Two IEC320-
C19 (8A ea)
Input: 3.6m attached
cable with L6-30P
Output: Four IEC320-
C19 (12A ea)
Input: 3.6m attached
cable with IEC309-32A
Output: Four IEC320-
C19 (12A ea)
Input: Hardwire
Output: Four IEC320-
C19 (12A ea)
Note: Manual ON/Off control provided for each load group; switch guards provided to prevent inadvertent power Off. The Control unit for the 16A model
has 2 outputs while the Control Unit for all other Modular PDUs has 4 outputs. The Extension Bars plug directly into the output-ends of the Control
Unit.
Extension Bars (x4)*
*Except for the 16A
model, which has 2
Extension Bars
Input: 2m attached
cord with IEC320-C20
Output: Each Bar has
8 NEMA 5-15 outlets
(12A max per outlet,
12A max per Bar)
Input: 2m attached
cord with IEC320- C20
Output: Each Bar has
8 C13 outlets
(10A max per outlet,
12A max per Bar)
Input: 2m attached
cord with IEC320- C20
Output: Each Bar has
8 C13 outlets
(10A max per outlet,
12A max per Bar)
Input: 2m attached
cord with IEC320- C20
Output: Each Bar has
8 C13 outlets
(10A max per outlet,
12A max per Bar)
Input: 2m attached
cord with IEC320- C20
Output: 3 Bars each
with 8 C13 (10A max
per outlet, 12A max
per Bar); 1 Bar with 4
C19 (12A max per
outlet, 12A max per
Bar)
