Power Supply
Operating Voltage Range (STD PS)
Operating Voltage Range (EPA 87/89/85% @ 20/50/100% load PS)
Rated Voltage Range (STD PS)
Rated Voltage Range (EPA 87/89/85% @ 20/50/100% load PS)
Rated Line Frequency
115V
90-264 VAC
90-264 VAC
100-240 VAC
100-240 VAC
50-60 Hz
230V
90-264 VAC
90-264 VAC
100-240 VAC
100-240 VAC
50-60 Hz
Power Output 240W 240W
Rated Input Current (maximum)
1
STD PS
EPA 87/89/85% @ 20/50/100% load PS
4A @ 100 VAC
4A @ 100 VAC
2A @ 230 VAC
2A @ 230 VAC
1
This system utilizes an active power factor corrected power supply. This allows the system to pass the CE mark
requirements for use in the countries of the European Union. The active power factor corrected power supply also has the
added benefit of not requiring an input voltage range select switch.
Table E-1 Specifications (continued)
112 Appendix E Specifications
