20" LCD Color Monitor HP 2009M&2009F
41
Separate
the
bezel
and
shield.
Disconnect
the
connectors
remarked in
green
Remove the
main frame
Disconnect
the
connectors
remarked in
greenand
remove the
screws to
remove the
main frame.
Key cable
Audio cable
