20" LCD Color Monitor HP 2009M&2009F
51
R402 061G0805000 RST CHIP MAX 0R05 1/8W
R628 061G0805000 RST CHIP MAX 0R05 1/8W
R435 061G1206331 RST CHIPR 330 OHM +-5% 1/4W
C622 065G0402101 31 CHIP 100PF 50V NPO
C623 065G0402101 31 CHIP 100PF 50V NPO
C106 065G0402102 32 1000PF +-10% 50V X7R
C708 065G0402104 12 CAP CHIP 0402 0.1UF 16V X7R
C709 065G0402104 12 CAP CHIP 0402 0.1UF 16V X7R
C406 065G0402104 15 MLCC 0402 0.1UF K 16V X5R
C405 065G0402104 15 MLCC 0402 0.1UF K 16V X5R
C404 065G0402104 15 MLCC 0402 0.1UF K 16V X5R
C428 065G0402104 15 MLCC 0402 0.1UF K 16V X5R
C424 065G0402104 15 MLCC 0402 0.1UF K 16V X5R
C423 065G0402104 15 MLCC 0402 0.1UF K 16V X5R
C421 065G0402104 15 MLCC 0402 0.1UF K 16V X5R
C418 065G0402104 15 MLCC 0402 0.1UF K 16V X5R
C415 065G0402104 15 MLCC 0402 0.1UF K 16V X5R
C414 065G0402104 15 MLCC 0402 0.1UF K 16V X5R
C413 065G0402104 15 MLCC 0402 0.1UF K 16V X5R
C412 065G0402104 15 MLCC 0402 0.1UF K 16V X5R
C411 065G0402104 15 MLCC 0402 0.1UF K 16V X5R
C410 065G0402104 15 MLCC 0402 0.1UF K 16V X5R
C409 065G0402104 15 MLCC 0402 0.1UF K 16V X5R
C408 065G0402104 15 MLCC 0402 0.1UF K 16V X5R
C407 065G0402104 15 MLCC 0402 0.1UF K 16V X5R
C430 065G0402104 15 MLCC 0402 0.1UF K 16V X5R
C703 065G0402104 15 MLCC 0402 0.1UF K 16V X5R
C704 065G0402104 15 MLCC 0402 0.1UF K 16V X5R
C705 065G0402104 15 MLCC 0402 0.1UF K 16V X5R
C432 065G0402104 15 MLCC 0402 0.1UF K 16V X5R
C425 065G0402104 15 MLCC 0402 0.1UF K 16V X5R
C426 065G0402104 15 MLCC 0402 0.1UF K 16V X5R
C427 065G0402104 15 MLCC 0402 0.1UF K 16V X5R
C403 065G0402104 15 MLCC 0402 0.1UF K 16V X5R
C402 065G0402104 15 MLCC 0402 0.1UF K 16V X5R
C116 065G0402104 15 MLCC 0402 0.1UF K 16V X5R
C111 065G0402104 15 MLCC 0402 0.1UF K 16V X5R
C121 065G0402121 31 CAP CHIP 0402 120PFJ 50V NPO
C104 065G0402220 31 CHIP 22PF 50V NPO
C105 065G0402220 31 CHIP 22PF 50V NPO
