Phillips PM 2.0×4.0 screw
Color Quantity Length Thread Head diameter
Black 16 4.0 mm 2.0 mm 4.5 mm
Where used: 1 screw that secures the Bluetooth module to the Bluetooth module compartment cover
Where used: 2 screws that secure the WLAN module to the base enclosure
116 Chapter 7 Screw listing
