IEEE 1394 (FireWire)
Pin
Signal
1
Twisted-pair B, differential signals
2
Twisted-pair B, differential signals
3
Twisted-pair A, differential signals
4
Twisted-pair A, differential signals
142
Chapter 9 Conn
ector pin assignments
149
