d. Rotate the display panel onto the keyboard (4) to gain access to the display cable connection on
the back of the panel.
NOTE: The display will not be connected to the computer as shown in the following image.
e. On the back of the display panel, release the adhesive strip that secures the display panel cable to
the display panel, and then disconnect the cable (1).
f. Remove the display panel from the computer (2).
NOTE: The display will not be connected to the computer as shown in the following image.
4. To remove the display hinges:
Component replacement procedures 67
